LED Modules
Front Service LED Modules Collection
Wholesales Price | Inventory Support | Local Repairing | Installation Service | 5 Years Warrenty
We offer high brightness LED Modules with multiple pixel pitches, which being in particular for outdoor advertising signs, commercial LED screen displays, sports displays, church led screens and more fixed installation led display projects. Also there are three main sizes of LED module which can be regarded as flexible options to be widely used for your LED screen projects.
Here is the basic technical parameters as following list.
| Module Size (mm) | Pixel Pitch (mm) | LED | Matrix Configuration pixels | Brightness Range | Driving Mode (Scan) | Service Type |
| 320 x 320 | P4 | SMD1921 | 80 x 80 | 5500~8000nits | 1/10 | Front Service |
| P5 | SMD1921 | 64 x 64 | 5500~8000nits | 1/8 | Front Service | |
| P6.67 | SMD2727 | 48 x 48 | 5500~10000nits | 1/4 or 1/6 | Front Service | |
| P8 | SMD2727 | 40 x 40 | 6000~10000nits | 1/4 | Front Service | |
| P10 | SMD2727 | 32 x 32 | 6500~10000nits | 1/2 | Front Service | |
| P10 | DIP346 | 32 x 32 | 7500~10000nits | 1/2 | Front Service | |
| P16 | DIP346 | 20 x 20 | 9000~10500nits | 1/2 | Front Service | |
| 304.8 x 304.8 | P6.35 | SMD2727 | 48 x 48 | 6500~10000nits | 1/4 or 1/6 | Front Service |
| P8.36 | SMD2727 | 36 x 36 | 7000~10000nits | 1/4 | Front Service | |
| P10.16 | SMD2727 | 30 x 30 | 10000nits | 1/2 | Front Service | |
| P10.16 | DIP346 | 36 x 36 | 10000nits | 1/2 | Front Service | |
| 250 x 250 | P2.976 | SMD1415 | 84 x 84 | 5500nits | 1/14 | Front Service |
| P3.91 | SMD1921 | 64 x 64 | 5500nits | 1/8 | Front Service | |
| P4.81 | SMD1921 | 52 x 52 | 5500nits | 1/9 | Front Service | |
| P5.95 | SMD1921 | 42 x 42 | 5500nits | 1/7 | Front Service |
